The SOCMA HNT5010-4Z 5 Ton 10 Meter Telehandler Forklift is engineered for versatile material handling in construction and logistics. With a 5-ton lifting capacity and a 10-meter reach, it combines robust performance with advanced 4WD/4WS capabilities for challenging environments.
The SOCMA HNT5010-4Z 5 Ton 10 Meter Telehandler Forklift is designed for demanding construction, agricultural, and logistics tasks. It features a 5-ton lifting capacity and a 10-meter telescopic boom, ideal for lifting and placing materials at height on uneven terrain.
Equipped with 4-wheel drive and 4-wheel steering, the HNT5010-4Z ensures excellent maneuverability and stability. Its hydraulic-mechanical transmission, hydraulic power steering, and hydraulic braking provide precise control, while the two-stage quadrilateral telescopic boom supports a side shifter and various attachments like buckets and hooks.
Powered by a Cummins turbocharged diesel engine with an air-to-air cooling radiator, the HNT5010-4Z delivers reliable performance and efficiency. The ergonomic cab includes a wide field of view, adjustable seating, and a multifunctional LCD monitor, ensuring operator comfort and safety.
Rated Load: 5 tons
Load Center: 500 mm
Lifting Height: 10000 mm
Max Outreach (Front Wheel to Load Center): 7000 mm
Load at Max Height (on Outriggers): 2500 kg
Wheelbase: 2900 mm
Weight: 9000 kg
Mast/Carriage Tilt Angle (Front/Rear): 6/12 degrees
Mast Height (Fork Lowering): 2500 mm
Height to Head Guard/Height to Cab: 2500 mm
Overall Length: 5800 mm
Fork Front Vertical Surface to Rear End of Vehicle: 4300 mm
Overall Width: 2300 mm
Fork Dimension: 1200x150x60 mm
Mast Min Ground Clearance (with Load): 280 mm
Wheelbase Center Min Ground Clearance (with Load): 330 mm
Min Turning Radius: 4700 mm
Travel Speed (with Load/without Load): 25/30 km/h
Max Lifting Speed (with Load/without Load): 240/260 mm/s
Max Lowering Speed (with Load/without Load): 310/290 mm/s
Traction: 4800 N
Gradeability (with Load/without Load): 20/22 %
Driving Brake: Hydraulic clamp disc
Tire Specs - Front: 16/70-24PR
Tire Specs - Rear: 10.00-20PR
Tires Qty (Front/Rear - Drive Wheels): 2/2
Wheel Tread - Front: 1850 mm
Wheel Tread - Rear: 1800 mm
Engine Brand/Model: Cummins QSB4.5-C125
Cylinder No.: 4
Transmission Gears (Front/Rear): 2/2
Attachments Working Pressure: 20 bar
Attachments Using Oil Amount: 230 l/min
