The SOCMA HNT7510-4Z 7.5 Ton 10 Meter Telehandler Forklift is built for heavy-duty construction, mining, and logistics tasks. With a 7.5-ton lifting capacity and a 10-meter reach, it offers robust performance with advanced 4WD/4WS capabilities for challenging environments.
The SOCMA HNT7510-4Z 7.5 Ton 10 Meter Telehandler Forklift is designed for demanding applications in construction, mining, and logistics. It features a 7.5-ton lifting capacity and a 10-meter telescopic boom, ideal for lifting and placing heavy materials in rugged environments.
Equipped with 4-wheel drive, 4-wheel steering, and a hydrostatic transmission, the HNT7510-4Z ensures excellent maneuverability and energy efficiency. Wet multi-disc hydraulic brakes and a reinforced arm frame provide safety and stability, while attachments like tire clamps make it suitable for mining operations.
Powered by a Cummins turbocharged diesel engine with an air-to-air cooling radiator, the HNT7510-4Z delivers reliable performance. The streamlined cab offers a wide field of view, joystick control, a reversing camera, and an integrated display, ensuring operator comfort and precision.
Rated Load: 7.5 tons
Load Center: 600 mm
Lifting Height: 10000 mm
Max Outreach (Front Wheel to Load Center): 7000 mm
Load at Max Height (on Outriggers): 3500 kg
Wheelbase: 3400 mm
Weight: 13500 kg
Mast/Carriage Tilt Angle (Front/Rear): 6/12 degrees
Mast Height (Fork Lowering): 2900 mm
Height to Head Guard/Height to Cab: 2700 mm
Overall Length: 6800 mm
Fork Front Vertical Surface to Rear End of Vehicle: 5400 mm
Overall Width: 2500 mm
Fork Dimension: 1200x150x60 mm
Mast Min Ground Clearance (with Load): 320 mm
Wheelbase Center Min Ground Clearance (with Load): 380 mm
Min Turning Radius: 5000 mm
Travel Speed (with Load/without Load): 25/35 km/h
Max Lifting Speed (with Load/without Load): 280/300 mm/s
Max Lowering Speed (with Load/without Load): 340/320 mm/s
Traction: 5700 N
Gradeability (with Load/without Load): 22/25 %
Driving Brake: Wet multi-disc hydraulic
Tire Specs - Front: 16/70-24PR
Tire Specs - Rear: 16/70-24PR
Tires Qty (Front/Rear - Drive Wheels): 4/4
Wheel Tread - Front: 1950 mm
Wheel Tread - Rear: 1950 mm
Engine Brand/Model: Cummins QSB4.5-C160
Cylinder No.: 4
Transmission: Hydrostatic
Transmission Gears: Automatic (4WD/4WS)
Attachments Working Pressure: 22 bar
Attachments Using Oil Amount: 280 l/min
