SOCMA HNTR4015-4Z 4 Ton 15 Meter Rotating Telehandler Forklifts For Construction and Industrial Use

Product Description

The SOCMA HNTR4015-4Z 4 Ton 15 Meter Rotating Telehandler Forklift is designed for demanding applications in construction, industrial sites, and municipal operations. It features a 4-ton lifting capacity, a 15-meter three-section telescopic boom, and a 360° rotating chassis, enabling multi-purpose functionality.

Equipped with 4-wheel drive and 4-wheel steering, the HNTR4015-4Z ensures excellent maneuverability on rough terrain. Its hydrostatic transmission, hydraulic stabilizers, and maximum horizontal reach of 10.5 meters allow it to serve as a telescopic forklift loader, crane loader, or aerial work platform.

Powered by a DF Cummins engine with an air-to-air intercooler, the HNTR4015-4Z delivers reliable performance. The cab includes ergonomic controls, a wide field of view, and a multifunctional LCD monitor, ensuring operator comfort and safety during extended operations.

Product Parameter

Rated Load: 4 tons

Load Center: 500 mm

Lifting Height: 15000 mm

Max Outreach (Front Wheel to Load Center): 10500 mm

Load at Max Height (on Outriggers): 2000 kg

Wheelbase: 3000 mm

Weight: 11000 kg

Mast/Carriage Tilt Angle (Front/Rear): 6/12 degrees

Mast Height (Fork Lowering): 2800 mm

Height to Head Guard/Height to Cab: 2600 mm

Overall Length: 6500 mm

Fork Front Vertical Surface to Rear End of Vehicle: 5100 mm

Overall Width: 2400 mm

Fork Dimension: 1200x150x60 mm

Mast Min Ground Clearance (with Load): 300 mm

Wheelbase Center Min Ground Clearance (with Load): 350 mm

Min Turning Radius: 4800 mm

Travel Speed (with Load/without Load): 25/35 km/h

Max Lifting Speed (with Load/without Load): 250/270 mm/s

Max Lowering Speed (with Load/without Load): 320/300 mm/s

Traction: 4500 N

Gradeability (with Load/without Load): 20/22 %

Driving Brake: Hydraulic clamp disc

Tire Specs - Front: 16/70-24PR

Tire Specs - Rear: 16/70-24PR

Tires Qty (Front/Rear - Drive Wheels): 4/4

Wheel Tread - Front: 1900 mm

Wheel Tread - Rear: 1900 mm

Engine Brand/Model: DF Cummins QSB4.5-C125

Cylinder No.: 4

Transmission: Hydrostatic

Transmission Gears: Automatic (4WD/4WS)

Attachments Working Pressure: 20 bar

Attachments Using Oil Amount: 240 l/min
